Disassembly and Assembly
25
Fans and Speakers Remove
1 Using a cross-head screwdriver, separate the 3 screws on the left fan and remove the
fan module.
Be careful not to damage the near components.
Check the number of screws that have been removed, and store them carefully
to make sure that no unassembled screws are left inside the computer during
assembly.
2 Using a cross-head screwdriver, separate the 3 screws on the right fan and remove
the fan module.
Be careful not to damage the near components.
Check the number of screws that have been removed, and store them carefully
to make sure that no unassembled screws are left inside the computer during
assembly.
