Disassembly and Assembly
22
SSD Remove
Use a cross-head screwdriver to remove the screw located on the SSD, then pull the SSD
horizontally out of the SSD socket to separate it.
Be careful not to damage the near components.
•
If two SSDs are installed, separate the other SSD using the same method.
•
Check the number of screws that have been removed, and store them carefully
to make sure that no unassembled screws are left inside the computer during
assembly.
1
2
After you finish disassembling, refer to SSD Assembly for how to reassemble.
