OfficeServ 7070 System Description/Ed.02OfficeServ 7070 System Description/Ed.02

2-29

2.4.5 Door Phone Interface Module

Door Phone Interface Module (DPIM) is the module that connects door phones and door

open/close devices to OfficeServ 7070. The line port of the door phone interface device is

connected to the DLI port of OfficeServ 7070 system. The door box port of the door phone

interface device is connected to the line port of the door phone.

Figure 2.27 DPIM

Reference

For information on how to connect terminals such as a door phone interface

device, refer to ‘OfficeServ 7070 Installation Manual’.
