Table 3.2 OfficeServ 7070 System Capacity
Module
Maximum Line Capacity
Basic cabinet
- Four (4) DLI ports: BMP (MAIN part) base (default installation board)
- Eight (8) SLI ports: BMP (B8S part) base
- Four (4) ATRK ports: BMP (B8S part) base
- PRM: One (1) is installed at the BMP (MAIN part) LOC1.
- 4DLM: Up to five (5) can be installed on the BMP (MAIN part) and
BMP (B8S part).
- 4SL2: Up to five (5) can be installed on the BMP (MAIN part) and
BMP (B8S part).
- 4TRM: Up to three (3) can be installed on the BMP (B8S part).
E8S
- 4TRM: Up to three (3) can be installed on the BMP (B8S part).
- Eight (8) SLI ports: E8S Base
- 4DLM: Up to three (3) can be installed.
- 4SL2: Up to three (3) can be installed.
- 4TRM: Up to three (3) can be installed.
PRM
PRI 30 lines
4TRM
ATRK 4Port
4DLM
DLI 4Port
4SL2
SLI 4Port
2BRM
BRI 4 lines
3.1.1 Trunk Line Capacity
The maximum trunk line capacity of OfficeServ 7070 based on its configuration is shown
in the table below:
Table 3.3 Trunk Line Capacity
System Configuration
Analog
Digital
LOOP TRK
T1 TRK
E1 TRK
PRI TRK
Basic cabinet
16
-
-
E1: 30
Basic cabinet +E8S
28
-
-
E1: 30
3.1.2 Station (Subscriber) Line Capacity
The maximum station line capacity for regular phones and digital phones in OfficeServ
7070 based on its configuration is shown in the table below:
Table 3.4 Station Line Capacity
System Configuration
Regular Phones
Digital Phones
Basic cabinet
28
24
Basic cabinet +E8S
48
36
