Alignment & Adjustment
3-12 Samsung Electronics
3-6 Replacements & Calibration
* Check items listed after changing each
Replaced Items Code No. Check Items
ASSY PCB MISC-MAIN BN94-00933B
1) Auto Program
2) White Balance Adjust
ASSY PCB P-SMPS(MAIN) BN96-03052A Vs, Va voltage check and adjust
ASSY PCB P-SMPS(DC DC) BN96-01856A Vscan, Vset, Ve voltage check and adjust
ASSY PDP P-LOGIC BOARD BN96-03106A
Not adjustment
ASSY PDP P-X MAIN BOARD BN96-03101A
ASSY PDP P-Y MAIN BOARD BN96-03102A
ASSY PDP P-Y MAIN SCAN BOARD BN96-03103A
ASSY PDP P-ADDRESS E BUFF BOARD BN96-03104A
ASSY PDP P-ADDRESS F BUFF BOARD BN96-03105A
※ When replacing the SMPS (DC DC) or PDP panel, you have to check the voltage printed on the panel sticker and adjust it.
※ The ASS'Y code can be changed, see "5 Chapter. Electrical Part List."
