Block Diagram
Samsung Electronics 7-5
7-2-4 Logic Board Block Diagram
60 Pin Connector FM75
30 Pin Connector 20 Pin Connector
60 Pin Connector
10 Pin (Power)31 Pin LVDS
DDR
(MA)
R,G,B : 24bit
CLK 1, 2
BLK, POC, STB
R,G,B : 24bit
CLK 1, 2
BLK, POC, STB
DATA : 32bit
ADDR : 12bit
DQS, CLK, nCLK
RELAY_EINT
Vs-ON
X-MAIN
CONTROL
SIGNAL
Y-MAIN
CONTROL
SIGNAL
LVDS SIGNAL
(8~12bit)
TX, RX
SCL, SDA
DRIVE
nRESET
5 Pin (uart)
ASIC
DDR
(FA)
DRIVE
RESET
