Alignment & Adjustment
3-14 Samsung Electronics
3. A point of adjusting SMPS-DC/DC.
* Use base chassis of PDP panel as GND point.
Test Point
Vset (Middle)
Vscan (Right)
Ve Test Point
Vscan/Vset
Adjustment
Point
VE
Adjustment
Point
