Samsung QB43B User Manual

71
Use WPS
"
This function may not be supported depending on the model.
How to set up using Use WPS
If your router has a Use WPS button, follow these steps.
1
Set Network Type to Wireless from the Open Network Settings page.
2
Select Use WPS, press E.
3
Press the WPS or PBC button on your wireless router within the next two minutes. Your
product automatically acquires all the network setting values it needs and connects to your
network.
– If you want to use the WPS PIN, select WPS PIN.
Go to your wireless router's Settings, enter your PIN, and then select OK.
4
The network connection screen appears, and network setup is done.

Samsung QB43B Specifications

General

Haze rate	2 %
Pixel pitch	0.245 x 0.245 mm
Response time	8 ms
RGB color space	DCI-P3
Color saturation	92 %
Display diagonal	43 \
Display brightness	350 cd/m²
Display technology	VA
Number of displays	1
Vertical scan range	48 - 75 Hz
Horizontal scan range	30 - 81 kHz
Display number of colors	1 billion colors
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (sleep)	0.5 W
Power consumption (typical)	110 W
Internal memory	8 GB
Computer system type	System on Chip (SoC)
Operating system installed	Tizen 6.5
USB ports quantity	2
HDMI ports quantity	3
DVI-I ports quantity	0
Package depth	151 mm
Package width	1095 mm
Package height	676 mm
Package weight	13300 g
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Orientation	Horizontal/Vertical
Mounting type	Wall
Product color	Black
Product design	Digital signage flat panel
Placement supported	Indoor
Panel mounting interface	200 x 200 mm
Purpose	Universal
HDCP version	2.2
Operating hours (hours/days)	16/7
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	48.3 mm
Display width	967.5 mm
Display height	557.7 mm
Display weight	10000 g
