Samsung SCL540 - Rear View

Rear View
ENGLISH
15
29. ZOOM
40. BATTERY EJECT
30. Cassette holder
41. SNAPSHOT/D.ZOOM
37. External MIC
31. Hooks for
shoulder strap
32. AUDIO/VIDEO out
29. ZOOM (see page 34)
30. Cassette holder
31. Hooks for shoulder strap (see page 21)
32. AUDIO/VIDEO out (see page 55)
33. LENS cap
34. Hand strap (see page 20)
35. LOCK/STANDBY (see page 22)
- LOCK : off
- STANDBY : CAMERA
36. START/STOP (see page 27)
START/STOP works in CAMERA mode.
37. External MIC (see page 66)
38. DC jack (see page 22)
39. Battery pack compartment (see page 23)
40. BATTERY EJECT
41. SNAP SHOT/D.ZOOM
SNAP SHOT works in CAMERA mode
(SCL530/L540/L550 only, see page 50)
D.ZOOM works in CAMERAmode
(SCL520 only, see page 36)
42. Recharging Indicator (see page 23)
33. LENS cap
34. Hand strap
35. LOCK/STANDBY
36. START/STOP
42. Recharging Indicator
38. DC jack
39. Battery pack
compartment
