Notices regarding rotation of LCD screen
ENGLISH
4
Please rotate the LCD screen carefully as illustrated. Unintended rotation may cause damage to the inside
of the hinge that connects the LCD screen to the Camcorder.
1) LCD screen closed.
2) Standard recording by using the LCD screen.
3) Making a recording by looking at the LCD screen
from the top.
4) Making a recording by looking at the LCD screen
from the front.
5) Making a recording with the LCD screen closed.
90°
90°
90°
1)
2)
3)
4)
5)
90°
✤ Do not let LENS point toward the sun.
Direct sunlight can damage the CCD
(Charge Coupled Device).
Notices regarding the LENS
