Exploded View/Disassembly&Assembly Instructions
5-6
This Document can not be used without Samsung's authorization
1. Separate LCD connector from sub-PBA
2. Remove the 2 rubbers with tweezers.
1. Separate sub-PBA from slide upper after
removing the camera and speaker module.
2. Separate LCD module from slide upper using
4 white points.
9
10
To Next Page
