Samsung Smart A/C application User Manual

English-4
Connecting network
Checking Wi-Fi module installation
1
f Open the lter cover and check the Wi-Fi Module (①) attached on the panel front. The connection status between the
Wi-Fi module and the wireless router can be checked by the Wi-Fi module described next page.
f To replace the Wi-Fi module(Assembling or disassembling), follow the procedure below.
• When changing the Wi-Fi module, you should check the MAC attached on the module or bottom part of the indoor
unit and modify the device information at ‘Registering service’.
Disassembling the Wi-Fi module
1. Remove the cover of the sub panel.
2. Disconnect the wire of the Wi-Fi module.
3. Release the hook on the top of the Wi-Fi module and push it up to disassemble it.
NOTE
A3050 ET WiFi APP_IB_04209A-00_EN.indd 4 2013-10-11 14:49:32
