English _111
APPENDIX
Item Details
Audio
Inputs / Output 16 line in (Built in 4CH, RCA) / 1 line out (RCA)
Compression ADPCM
Sampling rate 16KHz
Alarm
Inputs / Outputs
Terminal 16(8) inputs (NO/NC),Terminal 1 inputs (Alarm Reset),
Terminal 4 relay outputs (NO/NC), Rating : 24V DC/1A, 125V AC / 0.5A
Remote notification Notification via e-mail
Connections
Ethernet 1 RJ45 10/100/1000 Base-T
Serial interface RS-232/RS-485 for PTZ, System Keyboard
USB 3 USB Ports
e-SATA 2 External SATA ports
Application Supoort Mouse, Remote Controller
PTZ Protocol support
Samsung-E/ Samsung-T/ Pelco-D/ Pelco-p/Panasonic/ Phillips/AD/ DIAMOND/
ERNA/ KALATEL/ VCL TP/VICON
/ ELMO
(SRD-850DC/870DC/1650DC/1670DC : PTZ Control via Coaxial Cable (Samsung
CCVC, Coaxtron)
- Coaxial Transmission Distance : Max. 200m (based on 5C 2V)
- This is not available if the video repeater is connected.
General
Electrical
Input Voltage /Current 100 to 240 VAC ±10%; 50/60 Hz, Autoranging
Power consumption Max. 55 W (with 1x HDD)
Environmental
Operating Temperature
/ Humidity
+0°C to +40°C (+32°F to +104°F)/20%RH to 85%RH
Mechanical
Dimension (W x H x D)
H (leg not included)
440 x 88 x 426.8 mm (17.32 x 3.46 x 16.80 inch)
Weight (With hard
disks)
SRD-850/870 : Approx. 6.6Kg (14.5lb)
SRD-850D/850DC/870D/870DC : Approx. 7.4Kg (16.4lb)
SRD-1650/1670 : Approx. 6.7kg (14.8lb)
SRD-1650D/1650DC/1670D/1670DC : Approx. 7.6Kg (16.7lb)
Rack mount kit 2 EA
Lauguage
Korean, Japanese, Chinese (Simplified), English, French, German, Spanish, Italian,
Russian, Polish, Czech, Turkish, Netherlands, Portuguese,Swedish,Danish, Thailandais,
Rumania, Serbia, Croatia, Hungary, Greek
, Chinese (Traditional) (23 Language)
