14_ overview
overview
Part Names Functions

AUDIO IN
Audio input signal port (RCA jack) and port for optional audio extension cable.
SRD-1650/1650D/1650DC/1670/1670D/1670DC (Audio 5~16CH)
SRD-850/850D/850DC/870/870D/870DC (Audio 5~8CH)
b
AUDIO OUT Audio Signal Output Port (RCA jack).
c
VIDEO IN Composite Video Signal Input Port (BNC type connector).

LOOP OUT Used to transfer a video signal to other video devices.

VIDEO OUT Composite Video Signal Output Port (BNC type connector).

VGA VGA Video Signal Output Port.

HDMI HDMI connector port.

eSATA 1/2 Ports used for external storage device connections. (SATA HDD)

NETWORK NETWORK connector port.

USB USB connector port.

RS-485 Used for RS-485 communication. (TX+, TX-, RX+, RX-)

ALARM
- ALARM IN 1~16(SRD-1610/1610D/1610DC/1630/1630D/1630DC/1650/1650D/1650DC/
1670/1670D/1670DC) : Alarm Input port.
- ALARM IN 1~8(SRD-830/830D/830DC/850/850D/850DC/870/870D/870DC)
: Alarm Input port.
- ALARM RESET IN : Alarm Reset port.
- ALARM OUT 1~4 : Alarm Output port.
m
SPOT
A live screen output port, separate from the VIDEO OUT.
SRD-1670/1670D/1670DC : SPOT 1, 2, 3, 4
SRD-870/870D/870DC : SPOT 1, 2
SRD-830/830D/830DC/850/850D/850DC/1610/1610D/1610DC/1630/1630D/1630DC/1650/
1650D/1650DC : SPOT 1
n
AC 100-240V~ IN AC 100~240V(50~60Hz)
M
 [CONSOLE] is designed for the service repair purpose only.
