English _13
● OVERVIEW
Part Names Functions
Power Power connection port.
VIDEO OUT Composite Video Signal Output Port (VGA type connector).
SERIAL Serial port for connecting to a POS device.
SPOT1/2 BNC type of output port for the Spot signal.
VIDEO IN Video Signal Input Port (BNC type connector).
AUDIO OUT Audio Signal Output Port (RCA jack).
M
[CONSOLE] is designed for the service repair purpose only.
How to insert the power cable on the holder
<Inserting> <Separating>
HDMI
eSATA
VGA OUT
NETWORK
HDMI eSATA
VGA OUT
NETWORK
To Next Page
