English _67
● MAIN MENU
3. Press the [ENTER] button.
A backup window appears.
You can directly access it from the “Live screen menu”.
(Page 31)
4. Use direction buttons (◄ ►) to move to a desired item,
and set the value.
• Backup Range : Sets the <Start> and <End> time for the
backup.
• Channel : Sets the channel to backup.
You can select multiple channels.
• Device : Select a backup device from the recognized devi
ces.
• Type : Sets the backup data format.
- DVR : Saved data can be played back only by the DVR.
- SEC : Saves data in the Samsung’s proprietary format with built-in viewer, which supports immediate
playback on a PC.
• Filename : You can set the back file name.
Refer to “Using Virtual Keyboard”. (Page 42)
• Check capacity : Shows the size of the selected backup data, used and available capacity of the selected
backup device.
• Overlap : Shows a list of overlapping data on a same time according to the number of data.
It appears when one channel has multiple data on a certain time point due to changing of time or time zone
settings, etc.
Refer to time and time zone of “Setting the Date/Time/Language”. (Page 40)
5. When the backup setup is done, press <OK>.
If no available device is recognized for backup, <OK> button is not activated.
J
The application may slow down during the backup.
You can switch to the menu screen during the backup in operation, but playback of data is not available.
When a CD/DVD or memory device is used for backup, it is not available to use the full capacity of the media since the
system consumes a part of its capacity.
If a CD or DVD media causes errors, the disc tray opens and closes a several times, and eventually backup process will fail.
In this case, replace the CD/DVD media and try again.
If backup has failed, select “Device > Storage Device” and check the free space of the HDD and check also if the HDD is
properly connected.
M
Pressing the <Exit> during the backup will return to the previous menu, while the backup progresses.
Backup :
Used :
Free :
Check capacity
OK Cancel
Backup
Start 2012-01-01 00:01:06
End 2012-01-01 08:25:45
Overlap List0
Device
Internal CD/...
Type SEC
Folder \20120101\
Filename 0001
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
ALL
Change
To Next Page
