Configuring the PIP/PBP Settings
4
4 Configuring the PIP/PBP Settings
4.1.5 Configuring Source
Select the source for each screen.
Due to DisplayPort and Mini DP can't be identified at the same time, if DisplayPort and Mini DP as the
source at the same time ,the 'Apply' is not available.
PIP
1 Press any button on the front of the product to display the Function Key Guide. Next, press [ ] to
display the corresponding menu screen.
2 Press [ ] to move to PIP/PBP and press [ ] on the product.
3 Press [ ] to move to Source and press [ ] (available in PIP mode (Size / / )).
The following screen will appear.
U24E850R
If the function button description page appears, press [].
The main screen will switch in the order DisplayPort Mini DP
HDMI.
 DisplayPort
 Mini DP
 HDMI
→
→
Select the source for
each screen.
PIP/PBP
PIP/PBP Mode
Size
Position
Sound Source
Source
Picture Size
Contrast
DisplayPort
HDMI
On
