SAMWONTECH
2nd Edition of TEMP2000_Series IM : July. 16. 2010 Page 12 / 87
1.3.2 Terminal Assignment
1.3.2.1 TEMP2300 DISPLAY UNIT Terminals
1.3.2.2 TEMP2500/2700 DISPLAY UNIT Terminals
COM1
DISPLAY and CONTROL
COM2
DISPLAY and PC
Power(DC24V)
Power(DC24V)
COM1
DISPLAY and CONTROL
COM2
DISPLAY and PC
