SAMWONTECH
2nd Edition of TEMP2000_Series IM : July. 16. 2010 Page 14 / 87
1.3.2.5 I/O2 BOARD Terminals
COMCOMCOMCOM COM COM
RLY27RLY28RLY29RLY30 RLY31 RLY32
RLY26 RLY25 RLY24 RLY23 RLY22 RLY21 RLY20 RLY19 RLY18 RLY17 RLY16 RLY15 RLY14 RLY13
COM COM COM COM COM COM COM COM COM COM COM COM COM COM
I/O2 LINK
