4.3.2 Output by Retransmission Type
▶ Retransmission Output is 4~20mA.
▶ Attach 250Ω(Precision Resistor) between both Retransmission terminal when use 1~5V retransmission
output.
☞ When Retransmission Type is “PV” or “SP”
☞ When Retransmission Type is “MV”
4.0mA
12.0mA
20.0mA
Range Low Range High
(Range High+Range Low)/2
4.0mA
12.0mA 20.0mA
0.0% 100.0%
50.0%
