CW-3000 USER MANUAL
5
4. Maintenance
1. To ensure good heat dissipating, please open the lid to clean the dirt after the
cooler used in long-term.
2. Working in cold north area, it is better to use noncorrosive antifreeze fluid.
<4> SPECIFICATIONS
Model CW-3000AG CW-3000DG CW-3000AF CW-3000DF CW-3000AK CW-3000DK
Voltages AC220~240V AC100~120V AC220~240V AC100~120V AC220~240V AC100~120V
Frequency 50/60Hz
Current 0.45A 0.9A 0.45A 0.9A 0.5A 1.0A
Cooling 50W/ °C 60W/ °C
capacity 9 L
Inlet and
outlet hold
Outside dimensions
10mm brass connector
Inside dimensions
8mm speedy connector
Inside dimensions
6mm speedy connector
Max. pumping
lift
10 M 70 M
N.W 9.5Kg 12Kg
G.W 12Kg 14.5Kg
Dimensions 47X27X37cm (L X W X H)
Packing
dimensions
59X39X48cm (L X W X H)
