S&A CWUL-05 - Specifications

CWUL-05/10/20 Series
11
<6> Specifications
CWUL-05
Mode
CWUL-05AH
CWUL-05BH
CWUL-05DH
Voltage
AC 1P 220V
AC 1P 220V
AC 1P 110V
Frequency
50Hz
60Hz
60Hz
Current
0.25~2.1A
0.25~2.1A
0.38~2.45A
Nominal cooling
capacity
0.37KW
0.56KW
0.54KW
Refrigerant
R-134a
Precision
±0.2℃
Reducer
Capillary
Protection
Overcurrent protection for compressor, flow alarm, over temperature
alarm
Pump power
50 W
Inlet and outlet
External Ø10mm barbed connector
Max. lift
12M
Max. flow
13L/min
Tank capacity
6 L
N.W
23Kgs
G.W
26Kgs
Dimension
58X29X47 cm (L X W X H)
Package
dimension
70 X43X58 cm (L X W X H)
Note: The current and nominal cooling capacity could be different under different working
conditions and configurations. The above information is for reference only. Please subject to the
nameplate of the actual delivered product.The max. pump flow is obtained by testing the pump
individually on test criteria GB/T 3216-2005.
