7-7
7
SN3308 On-screen Messages
CHAPTER
Display Item Source Notes
RS232 PORT-1 OVERFLOW System An internal error message which
should never appear.
SCRATCHPAD CLEARED Pilot Appears when the map scratchpad
memory has been cleared by
pressing the "CLEAR" softkey
while in the map setup mode.
SETUP USING <SHFT-BRG> Pilot This message is displayed when
the Bearing Pointer is turned on
but both bearing pointer source
selections have been set to "OFF".
Use [SHFT]>[BRG] to assign at
least Bearing Pointer 1 to a
source, usually AUTO.
Vers: xx.xx CRC: xxxxxxxx POST At power up shows Software
Version and Cyclic Redundancy
Check. Write down the Software
Version Number prior to
contacting Sandel with technical
questions.
WX NOT INSTALLED Pilot Access to the [SHFT]>[WX] menu
is attempted when the WX-500
Stormscope is not installed.
YOU ARE TUNED TO AN ILS Pilot This message appears when
pressing the “NAV” switch on the
SN3308 to select a GPS or loran
and this action is overridden
because an ILS is tuned on NAV1.
