Model SA2-A Page 4 520-010-000 5/03
REASSEMBLY
All procedures for reassembling the pump are the reverse of the previous
instructions with further instructions as shown:
1. The diaphragm assemblies are to be installed with the natural bulge outward or
toward the head of the center screw. Make sure both plates are installed with outer
radii against the diaphragm. After all components are in position in a vise and hand
tight, set a torque wrench for 480 inch pounds (40 ft. pounds) (54.23 Newton meters)
using a (3/8") allen head socket. After each diaphragm sub assembly has been
completed, thread one assembly into the shaft (held near the middle in a vise having
soft jaws to protect the finish) making sure the stainless steel washer is in place on the
capscrew.
Make sure 1/4"-20 mounting screw has been removed and that the bumper (Item
#19 on drawing) is in place in the shaft.
Install this sub assembly into the pump and secure by placing the outer chamber
housing and capscrews on the end with the diaphragm. This will hold the assembly
in place while the opposite side is installed. Make sure the last diaphragm assembly
is torqued to 30 ft. lbs. (40.67 Newton meters) before placing the outer diaphragm over
the capscrews. If the holes in the diaphragm flange do not line up with the holes in the
chamber flange, turn the diaphragm assembly in the direction of tightening to align
the holes so that the capscrews can be inserted. This final torquing of the last
diaphragm assembly will lock the two diaphragm assemblies together. Place
remaining outer chamber on the open end and tighten down the securing nuts
gradually and evenly on both sides.
Caution should be used while reassembling check valves. The valves are
designed for some preload over the retainer hinge pad. This is done to insure proper
face contact with the seat. After all parts are in place, tighten the lock nuts down on
the assembly to the point where visual inspection shows that seat and valve face mate
without gap. This is important for dry prime. However, after priming action has started,
valves will function due to differential pressure without concern or trouble.
PILOT VALVE
The pilot valve assembly is accessed by removing the main air distribution valve
body from the pump and lifting the pilot valve body out of the intermediate housing.
Most problems with the pilot valve can be corrected by replacing the o-rings.
Always grease the spool prior to inserting it into the sleeve. If the sleeve is removed
from the body, reinsertion must be at the chamfered side. Grease the o-rings to slide
the sleeve into the valve body. Securely insert the retaining ring around the sleeve.
When reinserting the pilot valve, push both plungers (located inside the intermediate
bracket) out of the path of the pilot valve spool ends to avoid damage.
PILOT VALVE ACTUATOR
Bushings for the pilot valve actuators are threaded into the intermediate bracket
from the outside. The plunger may be removed for inspection or replacement. First
remove the air distribution valve body and the pilot valve body from the pump. The
plungers can be located by looking into the intermediate. It may be necessary to use
a fine piece of wire to pull them out. The bushing can be turned out through the inner
chamber by removing the outer chamber assembly. Replace the bushings if pins
have bent.
TROUBLESHOOTING
PROBLEM: Pump cycles but will not pump. (Note: higher suction lifts require faster
cycling speed for priming.)
POSSIBLE CAUSES:
A. Air leak in suction line.
B. Excessive suction lift.
C. Check valve not seating properly.
D. Leakage at joint of suction manifold or elbow flange.
E. Suction line or strainer plugged.
F. Diaphragm ruptured.
IMPORTANT
Before pump operation, all external
gasketed fasteners must be inspected
for looseness caused by gasket creep
after leaving the factory. Retorque loose
fasteners to insure against leakage.
Follow recommended torques where
called out. (A card is attached to each
new pump stating this fact.)
This pump is pressurized internally with
air pressure during operation. Always
make certain that all bolting is in good
condition and that all of the correct
bolting is reinstalled during assembly.
