1. DAB/FM Aerial
Always fully extend the aerial when
listening to the radio.
2. Earphones Socket
Connect headphones or earphones to this
socket.
3. AUX IN Socket
Connect AUX (Line) sources to this socket.
Controls and Connections
BACK VIEW
1
2 3 4 5 6
4. DC IN Socket
Connect the AC adapter to this socket
when using mains power.
5. Diagnostic Port Socket
For service engineers use only.
6. Battery Compartment Cover
Remove the cover to t batteries.
