TPMS1209C01 User Manual
Page 14 of 23
Press S key for a certain time to return to the index interface 5.
Contents of Alarm Records
Under the alarm record inquiry interface, press E to check alarm details. As
shown in left figure, it is the first alarm record which is also the latest alarm
The first screen displays the detailed alarm information, as shown in left
figure, alarm happened to front left tire, the pressure is 32.8 psi, the
temperature is 76℃, the alarm is high temperature, as shown in the figure.
Press S key to check the detail alarm time. As shown in left figure, year
and month when alarm happened are displayed.
Press S key to inquire the time. As shown in left figure are date and hour.
Press S key to inquiry time. As shown in left figure is minute.
Under the inquiry interface, press E key to return to the alarm record
number interface.
