TPMS1209C01 User Manual
Page 2 of 23
I. S&T TPMS1209C01 Full-Time Direct TPMS
TPMS1209C01 is a full-time direct tire pressure monitoring system including one wireless Monitor and
four screw-on Transmitters. The system can also support monitoring of the spare tire and a two-tire trailer
if needed. But this requires purchase of extra replacement transmitter. The Transmitters can be screwed
onto the tire valve to replace the original valve cap to sense the pressure inside the tire all the time, and
transmit the pressure information data to the Monitor by RF technology.
The Monitor receives the data and displays the pressure on the screen. The Monitor will issue different
alarms if the tire pressure is over or under an improper state based on the standard pressure.
S&T TPMS1209C01 will sense and display the tire pressure and temperature all the time and can issue an
alarm when the tire pressure or temperature is at an improper level, so as to notify the driver to treat the
problem and prevent tire damage. With the TPMS1209C01, the driver can monitor the pressure and
temperature to avoid excess gasoline consumption and keep the vehicle at the proper pressure.
-----------------------------------------------------------------------------------------
II. Parts of S&T TPMS1209C03
Monitor Transmitter
TPMS1209C01 Parts
1 Monitor
4 Transmitters
4 Security Locks
1 Lighter Plug
4 Counterweights (each 10g)
2 Wrenches
1 User Manual
1 Warranty Card
