Sanus BLT3 - Attach TV Brackets to TV; STEP 2: ATTACH WALL PLATE TO WALL

5
2
SECURELY TIGHTEN
1.3 Attach TV Bracket Assembly to TV
1
POSITION
TIP:
The tilt tension knob
T
on TV brackets
04
/
05
should be
oriented to the outside edges.
T
T
5⁄16 in. x 2 ¾ in.
Fischer UX10 x 60R
08
10
09
Parts and Hardware for STEP 2
Lag Bolt
Wall Plate
Wall Plate Template
Hex Key
3/16 in.
Concrete Anchor
For concrete installations ONLY
CAUTION: Do not use in drywall or wood
ATTACH WALL PLATE TO WALL
STEP 2
4X
01
02
02
03
01
NO SPACER SPACER NEEDED
A B
(qty. 1)
06
(qty. 1)
07
(qty. 1)
(qty. 4)
(qty. 4)
WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included
and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts!
NOTE: Not all hardware included will be used.
05
04
Brackets should be parallel with one another.
CAUTION:
