Sanus BLT3 - Concrete;Block Wall Installation

7
Skip to STEP 3 on PAGE 9.
4X
TIP:
TIP:
To calculate your precise wall plate location, check out
our HeightFinder at sanus.com [www.sanus.com/1172].
Min. 16 in. (40.6 cm)
1
POSITION TEMPLATE
Solid Concrete or Concrete Block Installation
● Mount the wall plate
07
directly onto the concrete surface
● Minimum solid concrete thickness: 8 in. (20.3 cm)
● Minimum concrete block size: 8 x 8 x 16 in. (20.3 x 20.3 x 40.6 cm)
● Minimum horizontal space between fasteners: 16 in. (40.6 cm)
● For concrete applications, TV brackets
04
/
05
must remain
centered in wall plate
07
. Keep this in mind when selecting
the wall plate location
STEP 2B
CAUTION: Avoid potential personal injury or property damage!
sanus.com
/1172
HeightFinder™
Visit
Never drill into the mortar between blocks.
CAUTION:
Never drill into the mortar between blocks.
2
DRILL
4X
CAUTION:
CAUTION: Avoid potential personal injury or property damage!
4X
08
07
09
4X
Be sure the anchors
09
are seated flush
with the concrete surface.
CAUTION:
5
SECURELY TIGHTEN
3
REMOVE TEMPLATE
3/8 in.
(10 mm)
3 in. (7.6 cm)
34
INSERT ANCHORS
06
06
06
Open
covers
Close
bottom
cover
Do not over-tighten the lag bolts
08
. Tighten the lag bolts only until they are pulled firmly
against the wall plate
07
.
