Sanwa CD731 - Default Chapter; Table of Contents

CONTENTS
【1】 SAFETY PRECAUTIONS : Before use, read the following safety precautions
1-1 Explanation of Warning Symbols …………………………029
1-2 Warning Instruction for safe use …………………………029
1-3 Maximum Overload Protection Input ……………………030
【2】APPLICATION AND FEATURES
2-1 Application……………………………………………………031
2-2 Features………………………………………………………031
【3】NAME OF COMPONENT UNITS
3-1 Multimeter, Test leads ……………………………………031
3-2 Display ………………………………………………………032
【4】DESCRIPTION OF FUNCTIONS ……………………………033
【5】MEASUREMENT PROCEDURE
5-1 Start-up Inspection …………………………………………035
5-2 Voltage measurement………………………………………036
5-2-1 DCV Measurement ( ) ………………………………036
5-2-2 ACV Measurement (〜) ………………………………036
5-3 Resistance Measurement (Ω) ……………………………038
5-4 Checking Continuity( ) ……………………………………038
5-5 Testing Diode ( ) …………………………………………039
5-6 Current Measurement (A) …………………………………040
5-6-1 DC/AC μA・mA ………………………………………040
5-6-2 DC/AC 20A………………………………………………041
5-7 How to use optional products ……………………………042
5-7-1 HV Probe (HV-60) ………………………………………042
5-7-2 AC Clamp Probe (CL-20D) ……………………………042
5-7-3 DC・AC Clamp Probe (CL-22AD) ……………………043
5-7-4 DC Clamp Probe (CL33DC) ……………………………043
【6】MAINTENANCE
6-1 Maintenance and inspection ………………………………044
6-2 Calibration ……………………………………………………044
6-3 How to Replace Battery and Fuse ………………………044
6-4 Storage ………………………………………………………045
【7】AFTER-SALE SERVICE
7-1 Warranty and Provision ……………………………………046
7-2 Repair…………………………………………………………046
7-3 Sanwa web site ……………………………………………047
【8】SPECIFICATIONS
8-1 General Specifications………………………………………047
8-2 Optional Accessories ………………………………………049
8-3 Measurement Range and Accuracy ………………………049
