[3] NAMES OF COMPONENT UNITS
3-1 Meter
Removabletestpincovers
 Whennotcovered：CAT.Ⅱ1000V
 Whencovered：CAT.Ⅲ600V
Select button
LCD display
Range hold
button
Relative button
Power switch &
function switch
Data hold/backlight
button
Measuring
terminal
COM (common)
terminal
Continuity lamp
Safety cap
measuring
terminal
10A measuring
terminal
3-2 Test Leads
1.5V
