Sanwa CD771 - Frequency Measurement (Hz)

—
11
—
Never use the meter for
measuring frequencies to ground
as the earth leakage breaker
may trip.
CAUTION
5-3-3 Continuity check (00)
Resistance
measurement
Diode test
Continuity check
Selection

Continuity lamp on
Remarks:
•
Continuity buzzer
sound and continuity
lanp on range: 0  ~
85  (±45 )
Remarks:
•
Because the Hz function uses
input resistance as low as approx.
2 k, a large amount of current
will flow during measurement.
Never use the meter for
measuring circuits or devices
having a small current capacity.
Function Max. Rated Input Range
100.0kHz
5.000Hz, 50.00Hz, 500.0Hz, 5.000kHz,
(1000Vrms) 50.00kHz, 100.0kHz (Auto range only)
5-4 Frequency Measurement (000)
Measurement prohibited
7 DRAWING No. CD771 03-1101 2040 6017
