22
—
Range Accuracy Input Resistance Remarks
Range Accuracy Input Resistance Remarks
Frequency
5.000Hz
50.00Hz
500.0Hz
5.000kHz
50.00kHz
100.0kHz
Range Accuracy Remarks
±(0.3%rdg+3dgt)
•
Auto range only
•
The data hold and relative functions cannot be
used.
•
Sensitivity: 3 Vrms or over.
•
Frequency less than 1 Hz cannot be measured.
•
Input resistance ≧ Approx. 2 k
•
Because the input resistance is as low as approx.
2 k, a large amount of current will flow during
measurement. Never use the meter for measuring
circuits or devices having a small current capacity.
Never use the meter for measuring frequencies to
ground as the earth leakage breaker may trip.
• Accuracy after canceling the indicated
value by the relative function.
• Auto range only
• The input resistance
excludes the fuse
resistance.
DCA
400.0µA
4000µA
40.00mA
400.0mA
4.000A
10.00A
±(1.4%rdg+3dgt)
±(2.0%rdg+3dgt)
Approx. 100
Approx. 1
Approx. 0.01
Capacitance
50.00nF
500.0nF
5.000µF
50.00µF
100.0µF
Range Accuracy Remarks
±(5.0%rdg+10dgt)
ACA
400.0µA
4000µA
40.00mA
400.0mA
4.000A
10.00A
±(1.8%rdg+5dgt)
±(2.4%rdg+5dgt)
Approx. 100
Approx. 1
Approx. 0.01
• Accuracy guarantee
frequency range:
40 Hz 400 Hz
(sinusoidal wave)
• The input resistance
excludes the fuse
resistance.
*
Maximum 20A can be measured if the measurement time is less than 10
seconds. (Take 10 minutes or longer intervals between measurements.)
DRAWING No. CD771 03-1101 2040 6017
