22
—
1) Application
Measures capacitance of capacitance.
2) Measuring ranges
6 ranges from 50.00nF to 9999µF
3) Measurement procedure
Connect the plug of black test lead to COM measuring input
terminal and plug of red test lead to measuring terminal.
Set the function switch at ' '.
Apply the red and black test pins to an object to measure.
Read the value on the display.
After measurement, release the red and black test pins from
the object measured.
Note:
While data communication to PC, Capacitance can be measured
up to 500.0µF range because of low response speed for large
capacitance measurement.
5-5-4 Capacitance Measurement
Discharge the capacitance before measurement.
CAUTION
③
①
④
②
⑤⑤
