RANGE Accuracy Burden Voltage
50Hz – 60Hz
500.00µA
0.15mV/µA
5000.0µA
50.000mA
1.0%rdg + 4dgt 3.3mV/mA
500.00mA
5.0000A
0.03V/A
10.000A*
40Hz – 1KHz
500.00µA
0.15mV/µA
5000.0µA
50.000mA
1.0%rdg + 40dgt 3.3mV/mA
500.00mA
5.0000A
0.03V/A
10.000A*
*10A continuous.
DC Loop Current %4~20mA
Accuracy: ±25dgt
4mA = 0% (zero) 20mA = 100% (span) Resolution: 0.01%
RANGE Accuracy Burden Voltage
500.00µA 0.15%rdg + 20dgt
0.15mV/µA
5000.0µA 0.1%rdg + 20dgt
50.000mA 0.15%rdg + 10dgt
3.3mV/mA
500.00mA 0.1%rdg + 20dgt
5.0000A 0.5%rdg + 10dgt
0.03V/A
10.000A* 0.5%rdg + 20dgt
*10A continuous.
AC & AC+DC Current
DC Current
