Sanwa PC5000 - Page 41

RANGE Accuracy
500.00Ω
5.0000kΩ
0.2%rdg + 6dgt
50.000kΩ
500.00kΩ
5.0000MΩ 0.8%rdg + 6dgt
50.000MΩ 2.0%rdg + 6dgt
—
38
—
Open Circuit Voltage: < 1.3VDC (< 3VDC for 500Ω range)
Capacitance
ΩOhms
RANGE Accuracy*
50.00nF
0.8%rdg + 3dgt
500.0nF
5.000µF 1.0%rdg + 3dgt
50.00µF 2.0%rdg + 3dgt
500.0µF 3.5%rdg + 5dgt
9999µF 5.0%rdg + 5dgt
*Accuracies with film capacitor or better
Hz Line Level Frequency
RANGE Accuracy
5.0000Hz~200.000kHz 0.002%rdg + 4dgt
Sensitivities (Sine RMS):
0.1V min @500mV range
1V min @5V range
10V min @50V range
100V min @500V range
900V min @1000V range
Hz Logic Level Frequency
RANGE Accuracy
5.0000Hz~2.00000MHz 0.002%rdg + 4dgt
Sensitivity: 2.5Vp square wave
