Specifications and external appearance of the product described
above may be revised for modification without prior notice.
—
39
—
Range Accuracy
Test Current Open Circuit
(Typical) Voltage
5.0000V 1%rdg + 1dgt 0.8mA < 3.5 VDC
Audible Continuity Tester
Audible threshold: between 20Ω and 200Ω Response time
< 100µs
Crest mode (Instantaneous Peak Hold)
Accuracy: Specified accuracy ±100 digits for changes > 0.8ms in
duration
%Duty Ratio
RANGE Accuracy
0.1% – 99.99% 3dgt/kHz + 2dgt
Input Frequency: 5Hz – 500 kHz, 5V Logic Family
Diode Test
