In the case when the operation is started after selection of liquid sterilization cycle,
sterilization/heat-retention cycle or equipment sterilization cycle
9. Press the button.
• When the sterilization setting time is longer than
the heat-retention time shown in the table below,
1) Press the button.
The process starts.
The cooling fan is operated automatically after
the completion of sterilization.
If the cooling fan operation not needed, press the
cooling fan button to turn OFF.
• On sterilization setting time
The sterilization time is based on Japanese
Pharmacopeia and the standards of JIS T 7324-2005
Small-sized High-pressure Steam Sterilizer for Medical
Use and it does not guarantee the sterilization. Be sure
to confirm the sterilization by sterilization indicator.
• The COVER LOCK lamp lights up after starting.
When the lamp is lit, the movable handle is locked to
make it impossible to open the cover.
If the cover is not closed completely, (cautionary
message) appears on the digital display II. In this case,
bring down the handle again and press the button
when the buzzer sounds.
• When the sterilization setting time is shorter
than the heat-retention time shown in the table
below,
1) Press the button.
The sterilization setting temperature appears on
the digital display I and the sterilization setting
time and cycle appear alternately on the digital
display II.
Confirm the setting.
2) Press the button.
The process starts.
Beep
In the case when the operation is started after selection of melting/heat-retention cycle
1) Press the button.
The melting setting temperature appears on the digital
display I and the sterilization setting time and cycle
appear alternately on
the digital display II.
2) Press the button.
The process starts.
• When the cover is opened after the completion of
process, the cycle/program is set automatically at
the 1-1 program of the liquid sterilization cycle.
When the temperature inside the chamber reaches
the melting setting temperature, the temperature
inside the chamber appears on the digital display I
and the sterilization remaining time or melting
remaining time appears on the digital display II.
Beep
Beep
37Min.
27Min.
22Min.
12Min.
10Min.
Advisory note
Beep
Beep
Liquid Sterilization
Heat-retention Time
115
121
126
132
135
Sterilization Setting
Temperature (°C)
30Min.
20Min.
15Min.
5Min.
Equipment Sterilization
Heat-retention Time
3Min.
Temperature inside chamber
Cover is not closed.
Sterilization remaining time or
melting remaining time
(after the temperature reaches the
sterilization temperature or melting
temperature)
To Next Page
