KT5-DHT100L00
PACKING MATERIALS
610 344 0545 CARTON CASE-KT5AL
610 344 8701 SPACER-KT5AL
610 343 9105 CUSHION BTM-KH5AL
610 343 9099 CUSHION TOP-KH5AL
645 099 7266 POLY BAG-1100X0850*NC*R8P
ACCESSORIES
COLOR WHEEL FOR COLOR
CW1 610 342 7713 COMPL HOLD CW COLOR-KH5AL
CW2 610 342 7713 COMPL HOLD CW COLOR-KH5AL
OWNER’S MANUAL
910 319 5347 COLOR MANAGE INST-B-MM7A
610 344 0804 SETUP INST MANUAL-KT5AL
610 346 1908 CD-ROM,OWNERS MANUAL-KT5AL-A
REMOTE CONTROL
645 099 0199 ASSY,REMOCON CXZZ
610 342 0400 RC-BATTERY LID-CXZL
AC CORD HOLDER
US 610 342 7744 HOLDER AC CODE US-KH5AL
EU/UK 610 342 7751 HOLDER AC CODE EU-LH5AL
! AC CORD
US 945 069 2902 CORD,POWER-3.0MK,US
EU 945 066 7160 CORD,POWER-3.0MK,EU
UK 945 066 7153 CORD,POWER-3.138MK,UK
MISCELLANEOUS
610 344 8763 COMPL,ACC COVER CODE-KHA5AL
610 344 8770 COMPL,ACC COVER SUPORT-KHA5AL
910 319 0588 STRAP COMP-MM7A
945 072 1121 CD-ROM (R.C. MANAGER)
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
945 050 8418 CORE,CLAMP
CABINET PARTS
C01 610 335 5092 COMPL,STAND LEG-KC3BL
C02 610 343 6258 BUTTON LNS-KH5AL
C03 610 343 6265 BUTTON CONTROL-KH5AL
C04 610 342 8666 CABINET FRONT-KH5AL
C05 610 342 8697 CABINET TOP-KH5AL
C06 610 342 8680 CABINET TOP COVER-KH5AL
C07 610 342 8673 CABINET BOTTOM-KH5AL
C08 610 342 7799 COVER NON LNS-KH5AL
C09 610 343 0003 COVER BOTTOM-KH5AL
C10 610 343 5633 COVER FILTER-KH5AL
C11 610 343 6807 COVER LNS-KH5AL
C12 610 343 9082 COVER SCREW CAB TOP-KH5AL
C13 610 343 6272 DEC INLAY LED-KH5AL
C14 610 343 6289 DEC INLAY RC FRONT-KH5AL
C15 610 343 6296 DEC INLAY LED AV PNL-KH5AL
C16 610 342 5665 DEC SHEET RC REAR-KH7AL
C17 610 342 9564 DEC AV SHEET-KH5AL
C18 610 344 0484 DEC AC SHEET-KH5AL
C19 610 343 5657 HANDLE A-KH5AL
C20 610 343 5671 HANDLE B-KH5AL
C21 910 283 5855 KNOB-MJ6A
C22 910 300 6940 PANEL COMP A-IDFV
C23 610 345 4160 PANEL COMP A-KH5AL
C24 610 342 9267 PNL AV-KH5AL
C25 610 344 8459 SPACER AC SHEET US-KH5AL
C26 610 346 2325 SPACER COVER BTM-KH5AL
C27 610 344 3942 BADGE SANYO-KH5AL
CHASSIS PARTS
M01 610 334 3747 ASSY,BOX FILTER-KC3A
M02 610 342 6785 ASSY,HOLDER LNS A-KH5AL
M02-1 945 042 7344 ASSY,MOTOR(ML6A)
M02-2 645 099 7716 UNIT,LENS,SHIFT-X,KH5AL
M02-3 645 099 7723 UNIT,LENS,SHIFT-Y,KH5AL
(Including Key No. M02-1 to M02-3)
M03 610 342 9335 COMPL,MOUNTING SHUTTER-KH5AL
M04 610 342 9342 COMPL,MOUNTING DB-KH5AL
M05 610 343 6357 ARM LNS LOCK X-KH5AL
M06 610 343 6364 ARM LNS LOCK Z-KH5AL
M07 610 344 4062 COVER SCREW LNS-KH5AL
M08 610 343 8405 COVER PFC PWB-KH5AL
M09 610 334 3549 GEAR MOTOR-KC3A
M10 610 345 2975 HEAT PIPE DMD-KH5AL
M11* 610 344 3874 HEAT SINK SHEET DMD-KH5AL
M12 610 343 0669 HOLDER FILTER DUCT-KH5AL
M13 610 343 0676 HOLDER FILTER-KH5AL
M14 610 343 0690 HOLDER FILTER BASE-KH5AL
M15 610 343 6333 HOLDER AC BRKT-KH5AL
M16 610 343 6326 HOLDER BALLAST-KH5AL
M17 610 343 6371 HOLDER RC FRONT-KH5AL
M18 610 343 6388 HOLDER CONTROL-KH5AL
M19 610 343 6791 KNOB LNS KH5AL
M20 610 334 4300 MTG HLD SHAFT FIL-KC3A
M21 610 344 4284 SPACER NUT-KH5AL
M22 610 344 0354 SPACER AC BRKT-KH5AL
M23 610 343 9075 SPACER CUSHION DMD-KH5AL
M24 610 346 5173 SPACER CUSHION DMD B-KH5AL
M25 610 343 9204 SPACER KAPTON SHEET KH5AL
M26 610 343 7804 SHIELD DMD-KH5AL
M27 610 343 9020 SPRING SPACER DMD-KH5AL
M28 610 343 9037 SPRING BUTTON LNS-KH5AL
M29 610 343 9044 SPRING LNS LOCK-KH5AL
M30 610 346 1045 SPRING DMD-KH5AL
M31 610 343 5367 OPTICAL LMP COVER-KH5AL
M32 610 343 5602 OPTICAL LMP DUCT BOX-KH5AL
M33 610 343 5626 OPTICAL LMP DUCT A-KH5AL
M34 610 343 5619 OPTICAL LMP DUCT B-KH5AL
M35 610 343 8436 OPTICAL COVER TOP-KH5AL
M36 610 343 8443 OPTICAL COVER BTM-KH5AL
M37 610 345 6881 OPTICAL BASE ROD DUCT-KH5AL
M38 645 099 6955 HOLDER,FAN
M39 610 336 9921 COMP,HOLDER SHAFT FILTER-KC3A
* Key No. M11 (HEATSINK SHEET) must be replaced with new one when
DMD module or M10 (Heatsink Pipe DMD) is removed.
SCREWS
S01 312 069 6702 SPECIAL SCREW(BLACK)
Key No. Part No. Description
Key No. Part No. Description
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Mechanical Parts List
