Sanyo PID-42AE1 Service Manual

11
Component / DVI Signal Support Timing List
r Component signal support timing
Resolution
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Remark
720 x 480 15.735 60i SDTV 480i
720 x 576 15.625 50i SDTV 576i
720 x 480 31.25 60p SDTV 480p
720 x 576 31.25 50p SDTV 576p
1280 x 720 45.00 60p HDTV 720p
1280 x 720 37.50 50p HDTV 720p
1920 x 1080 33.75 60i HDTV 1080i
1920 x 1080 28.13 50i HDTV 1080i
r
DVI-D signal support timing
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
Remark
640 x 480 31.43 59.88 VGA VESA 60Hz
640 x 480 37.86 72.81 VGA VESA 72Hz
640 x 480 37.5 75 VGA VESA 75Hz
640 x 480 34.97 66.6 MAC LC 13"
640 x 480 35 66.67 MAC_NORMAL 13"
800 x 600 35.16 56.25 SVGA VESA 56Hz
800 x 600 37.88 60.32 SVGA VESA 60Hz
800 x 600 46.875 75 SVGA VESA 75Hz
832 x 624 49.72 74.55 MAC_NORMAL 16"
1024 x 768 48.36 60 XGA VESA 60Hz
1024 x 768 60.23 75.03 XGA VESA 75Hz
1024 x 768 56.47 70.07 XGA VESA 70Hz
1024 x 768 60.24 75.08 MAC_NORMAL 19"
1152 x 870 68.68 75.06 MAC_NORMAL 21"
1280 x 1024 63.98 60.02 SXGA VESA 60Hz
720 x 480 31.7 59.94 480p
720 x 480 15.73 59.94 480i
768 x 575 31.25 50 575p
768 x 575 15.63 50 575i
1280 x 720 37.5 50 720p - 50Hz
1280 x 720 45 60 720p - 60Hz
1366 x 768 48.36 60 WXGA
1360 x 768 47.7 60 WXGA
1920 x 1080 28.125 50 1080i - 50Hz
1920 x 1080 33.75 60 1080i - 60Hz
1920 x 1080 56.25 50 HDTV 1080p - 50Hz
1920 x 1080 67.5 60 HDTV 1080p - 60Hz
1920 x 1080 27.00 24 HDTV 1080p - 24Hz
1920 x 1080 28.13 25 HDTV 1080p - 25Hz
1920 x 1080 33.75 30 HDTV 1080p - 30Hz
Depending on the condition of signals and the ytpe and length of cables, these signals
may not be properly viewed.
To save the XGA Mode 1366 x 768 setting switch the monitor off then on using the
standby button.
