RS232C Command Tables
r
UK5 Read Command Table (Basic Command)
Command Item Note
CR0 Power On, Standby, power error,
CR1 Input Mode AV1, AV2, . . . , DVI, PC
CR WIDE Wide mode Auto, Normal, Full, . . .
CR PICTURE Picture mode Dynamic, Standard, . . .
CR SIGNAL Signal existence Signal/No signal
CR CHILD Child lock On/Off
CR PSAVE Power save On/Off
CRTM Panel usage time –––
CR RMC RC inhibition On/Off
CR MDL Model number Model number
r
Error code Table
Error code Note
?
• Receiving the data that cannot be decoded.
• The wrong indication of parameter.
(Wrong gured number, or wrong word is included)
000 Normal receiving. (no error)
102 If the command of out of range is directly entered valuable parameter.
103
No matching with Hardware.
(Command for optional function which is not equipped)
201
If the command of “Out of range” is entered by inclement or decrements by
numeric value.
301
While capturing the picture, no execution. Wait and transmit command
again.
402
While PIN code is in operation, no execution.
Wait and transmit command again.
101 The errors not including above.
