23
Mechanical Disassembly
Remove screws (A) x 14 (4 x 14) and screws (B) x 4 (M4 x 18)
A
A
A
A
A
A
A
A
A
B
B
B
B
A
A
A
A
A
Removal of BACK PLATE
