Sanyo PID-42AE1 Service Manual

28
PID-42AE1
CHASSIS PARTS
! 6550034861 ASSY,PWB,MAIN COMP N8FA
1
! 6550034854 ASSY,PWB,MAIN N8FA
2
! 6550030511 ASSY,PWB,KEY
3
! 6550030504 ASSY,PWB,LED
4
! 6550035752 ASSY,PWB,POWER
9450618087 TERMINAL,BOARD X2
POWER CORD
! 6520031548 CORD,POWER-150MM
UK
! 9450541149 CORD,POWER-3.138MK
EUROPE
! 9450541156 CORD,POWER-3.0MK
USA
! 6520030183 CORD,POWER-1950MM
OTHER COMPONENT(ELECT)
LCD PANEL 6451021021 LCD(LD420WUN-SBA1)
LVDS CABLE 6520031500 CORD 51P,51P-51P(LVDS)
CN3-KQ 9103306347 STANDARD WIRE ASSY-JPN
CN2-KR 6103495224 STANDARD WIRE
K39L-K19L 6103495231 STANDARD WIRE
KJ-39J 6103395722 STANDARD WIRE ASSY-JPN
CN200-CN4 6520027619 NON STANDARD WIRE ASSY
KSPR-SP 6520025431 NON STANDARD WIRE ASSY-JPN
KSPL-SP 6520025424 NON STANDARD WIRE ASSY-JPN
CHASSIS ELECTRICAL PARTS LIST
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by a mark in this parts list and the circuit diagram show components whose value have
special significance to product safety. It is particularly recommended that only parts specified on the following
parts list be used for components replacement pointed out by the mark .
!
!
Chassis Electrical Parts List
1
4
3
2
