Sanyo PID-42AE1 Service Manual

4
On-screen Service Menu System
To enter Installation Mode press and hold the green button on the remote control for 3
seconds.
Installation Mode allows the user to set up the function of the set.
To enter Service Mode press the menu button on the remote control to display menu OSD
and key in 3609 within 4 seconds.
r To select the service item and change data value
+ To select the adjustment item, use the Pe or P
d
buttons.
+ To change the service data, use the Volume - (LEFT) or Volume + (RIGHT) buttons.
+ The data which is set in the service mode is stored into the memory IC automatically.
EXAMPLE: Source : CVBS2PAL/ALL
Properties: Normal Red
Data: 200
r To exit service mode
+ Press the MENU button or turn off the LCD Monitor by using the Mains switch.
INSTALLATION MODE
SERVICE MODE
Installation Mode
On program
Tuner Menu
Max Volume
Winter mode
RC inhibition
Child Lock
Address
Baud rate
Panel protection
AV Auto shut off
Network Standby
On Timer Function
LED light setting
DCR
Network initial
Temperature Error
IP Address
Subnet
Gateway
DNS
Off
Off
63
Off
Off
Off
0
19200
Off
Off
On
Off
Off
Off
>>>
0
000000000000
000000000000
000000000000
000000000000
G2.02 0000
Select Adjust
MENU
Exit
ITEM NO.
SECTION ITEM
VALUE
