QuaDrive Engine
“QuaDrive” optical engine in the HF15000L, HF10000L, XF1000,
HP7000L and XP200L is a newly developed and highly advanced
version of the conventional 3LCD system, and features an additional
Color Control Device. By controlling the amount of yellow light,
the Color Control Device increases the level of color purity by
approximately 20% compared with our previous model.
*1
This gives
images remarkable levels of both brightness and color.
Specifications
PLC-HF/XF Series Lenses PLC-HP/XP Series Lenses
High-Resolution 2K Panels
New LCD panels with an inorganic
alignment layer offer higher
resolution than full HD, to display
Real 2K (2048 x 1080 dots) images.
Full-HD (1920 x 1080 dot) video from
Blu-Ray Discs can be displayed in the
original format without compression.
• 2K: PLC-HF15000L, HF10000L
• 1080p: PLC-HP7000L
Active Maintenance Filter (AMF)
The Active Maintenance Filter (AMF) sensor
detects the intake air volume. If the volume
is less than the prescribed level, the filter is
automatically advanced and a clean filter surface
is set in position. The filter can also be replaced without having to use
any tools.
• Available for: PLC-HF10000L, XF1000, HP7000L, XP200L
Newly Developed Active Maintenance Cleaner (AMC)
SANYO’s new projectors employ an Active Maintenance Cleaner
(AMC) that automatically cleans the filter on a regular basis and
includes a blockage-detecting sensor. If dust infiltrates a projector—in
particular, the optical engine at the heart of the projector—it adversely
affects brightness and contrast performance. Protection from dust
is therefore an extremely important part of maintaining a projector’s
capabilities. AMC incorporates three high-performance filters and
a special brush. After it brushes off and collects large dust particles
from the first filter, remaining smaller dust particles are captured by
an electrostatic honeycomb filter and an electrostatic pleated filter.
Even if the device is installed in a high location, such as a ceiling,
it is not necessary to clean the filter. It keeps functioning for 12,000
hours
*1
, without requiring maintenance.
• Available for: PLC-HF15000L
*1
When lamp control: Normal mode
is selected. This value is calculated
through the company’s independent
test in reference to the JIS D0207 test
method. The filter replacement period
is an estimate and changes according
to the use environment.
QuaDrive
3LCD Conventional Model
Y
0.7
0.8
X
More true & real color
3LCD Conventional model
Color control
device
Red
Yellow
Green
Blue
Color control
device
Prism
Prism
Screen
Projection with priority on brightness
Projection with priority on color reproduction
Projection lens
Independent control of yellow
Dust
Filter
Brush
Dust adhered on lter
First layer lter is cleaned automatically at regular time intervals
or when it detects clogs
Automatic brushing
for collection of dust Clean lter surface
First layer
WXGA
(1280 x 800)
XGA
(1024 x 768)
Fu ll HD
(1920 x 1080)
2K
(2048 x 1080)
Model name PLC-HF15000L PLC-HF10000L PLC-XF1000 PLC-HP7000L PLC-XP200L
Resolution 2K (2048 x 1080) 2K (2048 x 1080) XGA (1024 x 768) 1080p (1920 x 1080) XGA (1024 x 768)
Brightness (typical) 15000 Lumens 10000 Lumens 12000 Lumens 7000 Lumens 7000 Lumens
Panel System Color Control x 1 1.65” TFT Poly x 3 Color Control x 1 1.64” TFT Poly x 3 1.8” TFT Poly x 3 Color Control x 1 1.2” TFT Poly x 3 Color Control
1.3” TFT Poly x 3 Color Control x 1
Number of Pixels 6,635,520 (2,211,840 x 3) 6,635,520 (2,211,840 x 3) 2,359,296 (786,432 x 3) 6,220,800 (2,073,600 x 3) 2,359,296 (786,432 x 3)
Contrast Ratio (Full on / off) 3000:1 3000:1 4000:1 2700:1 2200:1
Aspect Ratio 17:9 17:9 4:3 16:9 4:3
Projection Lamp (s) 380W UHP x 4 380W UHP x 2 330W NSHA x 2 380W NSHA 330W NSHA
Voltage 200 - 240 V 120 - 240 V 100 - 240 V 100 - 240 V 100 - 240 V
Weight (lbs.) 103.6 lbs. 60.0 lbs. 60.8 lbs. 25.6 lbs. 25.1 lbs.
Dimensions (inch) 25.6 x 13.7 x 32.1 inch 20.9 x 10.6 x 29.8 inch 20.9 x 10.6 x 29.8 inch 14.6 x 7.4 x 17.3 inch 14.6 x 7.4 x 17.3 inch
Digital Interface (HDCP Compatible) DVI-D, HDMI DVI-D, HDMI DVI-D DVI-D, HDMI DVI-D
Analog Interface 5BNC, D-sub 15 pin, S-Video 5BNC, D-sub 15 pin, S-Video 5BNC, D-sub 15 pin, S-Video 5BNC, D-sub 15 pin, 3RCA, S-Video 5BNC, D-sub 15 pin, 3RCA, S-Video
Network Control / Admin. Yes Yes Optional (PJ Net) Yes / Optional (PJ Net) Optional (PJ Net)
Model Type (Zoom)
UD/Ratio Throw Ratio
F Stop
HF Series XF Series HF Series XF Series
LNS-W03/E Short (Fixed) 1:1 1:1 0.8:1 0.8:1 2.6
LNS-W01Z Short (Fixed) 10:0-0:10 8:0-0:8 1.2:1 1.2:1 2.5
LNS-W06 Short (x1.3) 10:0-0:10 8:0-0:8 1.2-1.5:1 1.2-1.5:1 2.3-2.8
LNS-W02Z Short (x1.3) 10:0-0:10 8:0-0:8 1.4-1.8:1 1.4-1.8:1 2.5-2.9
LNS-W04 Short (x1.3) 10:0-0:10 8:0-0:8 1.5-2.0:1 1.5-2.0:1 1.7-2.3
LNS-S04 Standard (x1.3) 10:0-0:10 10:0-0:10 2.0-2.6:1 2.0-2.6:1 2.0-2.3
LNS-S03 Standard (x1.3) 10:0-0:10 10:0-0:10 2.6-3.5:1 2.6-3.5:1 1.7-2.6
LNS-M02 Long (x1.3) 10:0-0:10 10:0-0:10 3.5-4.5:1 3.5-4.5:1 2.0–2.6
LNS-T02/E Long (x1.4) 10:0-0:10 10:0-0:10 4.4-6.2:1 4.4-6.2:1 2.0-2.9
LNS-T01Z Long (Fixed) 10:0-0:10 10:0-0:10 6.9:1 6.9:1 2.0
LNS-T03 Ultra Long (x1.4) 10:0-0:10 10:0-0:10 6.3-9.0:1 6.3-9.0:1 2.2-2.5
Model Type (Zoom)
UD/Ratio Throw Ratio
F Stop
HP Series XP Series HP Series XP Series
LNS-W34 Short (Fixed) 1:1 N/A 0.8:1 N/A 2.3
LNS-W32 Short (Fixed) N/A 1:1 N/A 0.8:1 2.5
LNS-W33 Short (x1.4) 10:0 - 1:1 3.1-1:3 1.3-1.8:1 1.2-1.8:1 2.1-2.8
LNS-W31A Short (x1.4) N/A 10:0 - 1:1 N/A 1.3-1.8:1 2.5-3.1
LNS-S32 Standard (x1.3) 10:0 - 1:1 3.1-1:3 1.8-2.3:1 1.7-2.3:1 1.7-2.1
LNS-S31 Standard (x1.3) N/A 10:0 - 1:1 N/A 1.8-2.3:1 1.7-2.0
LNS-T34 Long (x1.8) 10:0 - 1:1 3.1-1:3 2.3-4.2:1 2.3-4.2:1 2.1-2.8
LNS-T31A Long (x1.8) N/A 10:0 - 1:1 N/A 2.3-4.2:1 2.0-2.9
LNS-T32 Ultra Long (x1.4) 7:-1 - 1:1 10:0 - 1:1 4.2-5.7:1 4.2-6.0:1 2.1-2.7
LNS-T33 Ultra Long (x1.5) 7:-1 - 1:1 10:0 - 1:1 5.7-8.9:1 5.7-9.0:1 2.2-2.7
SANYO. . . Providing More Projector Solutions
Toll free:
888-337-1215 www.sanyoprojectors.com
©2011 SANYO North America Corporation.
