-8-
■ Mechanical disassemblies
AV
FN907
Lam
p ballast
5. ASS'Y - AV AND FAN (FN907) REMOVAL
1. Remove five screws and remove Ass'y AV.
2. Remove three screws and remove Fan (FN907).
See figure right.
6. ASS'Y - LAMP - BSALLAST REMOVAL
1. Remove six screws and remove Ass'y Lamp-ballast.
