-109-
KK8-WM550000, KK8-WM5500L00
PACKING MATERIALS
For PLC-WM5500
610 350 1703 CARTON CASE-KK8A
610 347 9286 SPACER LNS PACKING-KA8AL
For PLC-WM5500L
610 350 1697 CARTON CASE-KK8AL
Common
610 346 9249 POLY BAG
610 350 9730 CASE ACCESSORY-KW8AL
610 346 9287 CUSHION TOP
610 346 9263 CUSHION BTM-KA8AL
ACCESSORIES
OWNERS MANUAL
610 350 3912 CD-ROM,OWNERS MANUAL-KK8AL
655 003 7282 SETUP INST-KK8AL
REMOTE CONTROL
645 103 0191 ASSY,REMOCON MXAP
610 335 0530 RC-BATTERY LID-CXWP
AC CORD
!US 945 064 6363 CORD,POWER-3.0MK,US
!EU 945 054 1156 CORD,POWER-3.0MK
!UK 945 054 1149 CORD,POWER-3.138MK
!BRA 645 102 6996 CORD,POWER-2.5MK,BRA
MISCELLANEOUS
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
652 002 9552 CABLE,INTERFACE VGA
S11 411 219 5500 BOLT HEX-SCT 3X11
CABINET PARTS
C01 610 346 8457 ASSY STAND LEG-KA8AL
C02 610 346 8259 BUTTON CONTROL-KA8AL
C03 610 346 8310 BUTTON LNS REL-KA8AL
C04 610 352 3316 CAB TOP SRV-KK8A
C04-1 610 346 8211 DEC INLAY LED-KA8AL
C05 610 352 3392 CAB BTM SRC-KA8AL
C05-1 610 342 6891 BADGE SANYO-KH7AL
C06 610 346 8167 COVER PRSM-KA8AL
C07 610 352 2562 COVER LAMP-KA8AL
C08 610 346 8266 COVER CAB BACK-KA8AL
C09 610 346 8280 COVER FILTER-KA8AL
C10 610 349 3299 COVER HDL SRV-KA8AL
C11 610 346 8303 COVER WITHOUT LNS-KA8AL
C12 610 346 8235 DEC INLAY RC-KA8AL
C13 610 346 8228 DEC RING CAB BTM-KA8AL
C14 610 346 8495 DEC LEG-KA8AL
C15 610 352 2852 DEC AV SHEET-KK8AL
C16 610 346 8327 HLD BUTTON LNS-KA8AL
C17 610 346 8501 MOUNT LOCK-KA8AL
C18 610 350 0256 PNL AV-KK8AL
C19 610 346 8549 SPRING BUTTON LNS-KA8AL
C20 610 347 7626 CAP LENS-KA8AL
(PLC-WM5500 only)
CHASSIS PARTS
M01 610 346 9034 ASSY,FILTER BOX
M02 610 352 3415 COMPL MTG LNS-KK8A
M03 610 346 8914 COMPL MTG SHUT-KA8AL
M04 610 349 3336 COVER LNS TOP SRV-KA8AL
M05 610 349 3275 COVER LNS BTM SRV-KA8AL
M06 610 346 9164 GEAR MOTOR-KA8AL
M07 610 346 9171 GEAR FILTER UNIT-KA8AL
M08 610 346 3063 HOLDER INT PBS BTM-KA8AL
M09 610 346 3070 HOLDER INT PBS TOP-KA8AL
M10 610 346 8389 HLD LAMP HOUSE-KA8AL
M11 610 346 8334 HOLDER MIRROR B-KA8AL
M12 610 346 8341 HOLDER LMP FAN-KA8AL
M13 610 346 8365 HOLDER LNS RELAY-KA8AL
M14 610 346 8396 HOLDER POL IN
M15 610 346 8419 HOLDER POL IN F
M16 610 349 3305 HLD FILTER UNIT SRV-KA8AL
M17 610 347 0849 HOLDER LMP FN TOP-KA8AL
M18 610 349 3329 MTG DUCT PNL TOP SRV-KA8AL
M19 610 349 3312 MTG DUCT PNL BTM SRV-KA8AL
M20 610 346 8662 MTG DUCT PNL C-KA8AL
M21 610 349 3343 MTG MOTOR SRV-KA8AL
M22 610 346 9140 MTG GEAR-KA8AL
M23 610 352 2807 MTG FILTER UNIT(A)-KA8AL
M24 610 347 0467 MTG SPK-KA8AL
M25 610 347 4212 MTG DUCT PBS-KA8AL
M26 610 346 8976 SPC SHT POW BTM-KA8AL
M27 610 346 8983 SPC SHT POW FAN-KA8AL
M28 610 346 8990 SPC SHT BALLAST-KA8AL
M29 610 346 9003 SPC SHT HLD POW A-KA8AL
M30 610 346 9010 SPC SHT HLD POW B-KA8AL
M31 610 348 4495 SPC_HLD MAIN PWB-KA8AL
M32 610 347 9262 SPACER SPK BOSS-KA8AL
M33 610 348 4525 SHD LMP SW-KA8AL
M34 610 346 3056 OPTICAL BASE BTM-KA8AL
M35 610 346 8631 OPT BASE TOP-KA8AL
SCREWS
S01 411 052 9802 SCR OVL 3X8
S02 411 031 9304 SCR BIN 3X8
S03 411 219 5005 SCR FLT 5X10
S04 412 079 6201 SPECIAL SCREW
S05 412 079 6409 SPECIAL SCREW
S06 412 079 3408 SPECIAL SCREW V
S07 412 077 8108 SPECIAL SCREW-2.5X6
S08 312 070 3509 SPECIAL SCREW V
S09 412 079 4504 SPECIAL SCREW FINE 2.5X6
S10 312 062 5504 SPECIAL WASHER
OPTICAL PARTS
L01L* 610 350 4032 ASSY,PNL/PRISM L-KK8AL
L01R* 610 350 4063 ASSY,PNL/PRISM R-KK8AL
L02-R 645 101 6034 POLARIZED GLASS(IN/R)
L02-G 645 101 6041 POLARIZED GLASS(IN/G)
L02-B 645 103 0672 POLARIZED GLASS(IN/B)
L03 645 102 7047 LENS,INTEGRATOR(IN)
L04 645 102 7054 LENS,INTEGRATOR(OUT)
L05 645 101 1596 LENS,CONDENSER(OUT)
L06 645 101 1602 LENS,CONDENSER(R)
Key No. Part No. Description
Key No. Part No. Description
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Mechanical Parts List
