Sanyo PLC-XP56 User Manual

6PC Real Blue 29 0 ~ 63
7 PC Real Sharpness 0 0 ~ 31
8 PC Real Gamma 8 0 ~ 15
9 PC Real N.R. 1 0 ~ 2
10 PC Real PROGRESSIVE 1 0 or 1
11 AV Cinema Contrast 32 0 ~ 63
12 AV Cinema Brightness 32 0 ~ 63
13 AV Cinema Color 32 0 ~ 63
14 AV Cinema Tint 32 0 ~ 63
15 AV Cinema Red 32 0 ~ 63
16 AV Cinema Green 30 0 ~ 63
17 AV Cinema Blue 29 0 ~ 63
18 AV Cinema Sharpness 15 0 ~ 31
19 AV Cinema Gamma 8 0 ~ 15
20 AV Cinema N.R. 1 0 ~ 2
21 AV Cinema PROGRESSIVE 1 0 or 1
Group: 20 IP_Converter
0IMAGE_IN_FUNC_POL 0/0/0/0/0/ 0/0/0/0/0 0 or 1 000-b4 (reg 0) NTSC / PAL / 480p / 575p / 1035i / 1080i / 1080i50 / 720p / 480i / 575i
1IMAGE_IN_HD_SEL 1/1/1/1/1/ 1/1/1/1/1 0 or 1 000-b3
2IMAGE_IN_HD_POL 1/1/1/1/1/ 1/1/1/1/1 0 or 1 000-b2
3IMAGE_IN_VD_POL 1/1/1/1/1/ 1/1/1/1/1 0 or 1 000-b1
4IMAGE_IN_LPF_SEL 0/0/0/0/0/ 0/0/0/0/0 0 or 1 000-b0
5IMAGE_OUT_CLK_POL 0/0/0/0/0/ 0/0/0/0/0 0 or 1 001-b5
6IMAGE_OUT_HD_POL 0/0/0/0/0/ 0/0/0/0/0 0 or 1 001-b4
7IMAGE_OUT_VD_POL 0/0/0/0/0/ 0/0/0/0/0 0 or 1 001-b3
8IMAGE_OUT_CS_SEL 0/0/0/0/0/ 0/0/0/0/0 0 or 1 001-b2
9IMAGE_OUT_DEMUX 1/1/1/1/1/ 1/1/1/1/1 0 or 1 001-b1
10 IMAGE_OUT_THROUGH 0/0/1/1/0/ 0/0/1/0/0 0 or 1 001-b0
11 IMAGE_IN_TOTAL_H Same as G510 - G517 0 ~ 2047 002 / 003 Same as G510 - G517 Read only
12 IMAGE_IN_START_H 190/ 200/ 171/ 196/ 124/ 0 ~ 2047 004 / 005
124/ 113/ 219/ 190/ 205
13 IMAGE_IN_SIZE_H 9/10/9/9/8/ 8/10/10/9/10 0 ~ 15 006 Read only
14 IMAGE_IN_START_V, 10 / 15 / 32 / 26 / 13/ 0 ~ 1023 007 / 008
10 / 10 / 20 / 10 / 16
15 IMAGE_IN_SIZE_V, 250 / 295 / 490 / 0 ~ 1023 009 / 010
545 / 545 / 545 / 545/
725 / 250 / 296
16 CLAMP_H, 100 / 130 / 100 / 110 / 0 ~ 2047 011 / 012 NTSC / PAL / Comp480p / Comp575p /
45 / 45 / 88 / 115 / Comp1035i / Comp1080i,1080i50 / Comp720p / Comp480i /
130 / 100 / 110 / 45 / Comp575i / RGB480p / RGB575p / RGB1035i /
45 / 88 / 115 / 130 RGB1080i,1080i50 / RGB720p / RGB480i / RGB575i
17 CLAMP_L, 140 / 160 / 130 / 145 / 0 ~ 2047 013 / 014
70 / 70 / 142 / 145 /
160 / 130 / 145 / 70 /
70 / 142 / 145 / 160
18 IMAGE_OUT_DELAY_H, 0 ~ 2047 015 / 016 (reg 2) NTSC / PAL / 480p /
-Read only 575p / 1035i / 1080i,1080i50 /
19 SYNC_OUT_DELAY_H, 0 ~ 2047 017 / 018 720p / 480i / 575i
-Read only
20 SYNC_OUT_DELAY_V, - 0 ~ 2047 019 / 020
Read only
21 IMAGE_OUT_START_H, 0 Set 0 021 / 022
22 IMAGE_OUT_END_H, 2047 Set 2047 023 / 024
23 IMAGE_OUT_START_V, 0/ 0/ 0/ 0/ 0/ 0/ 0/ 0/ 0 0 ~ 2047 025 / 026 + F440
24 IMAGE_OUT_END_V, 517/ 618/ 1038/ 1250/ 0 ~ 2047 027 / 028
1119/1119/1490/517/618
25 G_Y_IN_OS, 0 / 0 0 ~ 255 029 (reg 3) Not_RGB / RGB
26 B_CB_IN_OS, 128 / 0 0 ~ 255 030
27 R_CR_IN_OS, 128 / 0 0 ~ 255 031
28 G2Y, 256 / 150 0 ~ 1023 032 / 033 (reg 4) Not_RGB / RGB
29 B2Y, 0 / 29 0 ~ 1023 034 / 035
30 R2Y, 0 / 77 0 ~ 1023 036 / 037
31 G2CB, 0 / 939 0 ~ 1023 038 / 039
32 B2CB, 256 / 128 0 ~ 1023 040 / 041
33 R2CB, 0 / 983 0 ~ 1023 042 / 043
34 G2CR, 0 / 917 0 ~ 1023 044 / 045
35 B2CR, 0 / 1003 0 ~ 1023 046 / 047
36 R2CR, 256 / 128 0 ~ 1023 048 / 049
37 HUE_M, 37 / 35 0 ~ 255 050
38 GAIN_M, 0 / 0 0 ~ 127 051
39 DG_M_R, 0 / 0 0 ~ 63 052 (reg 4) Not_RGB / RGB
40 HUE_R, 77 / 73 0 ~ 255 053
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments
-10-
