-54-
■ Waveform
VIDEO-IN <IC1141-4> Y-IN <IC3101-5>
C-IN <IC3101-7>
VIDEO_Y <IC3101-21> VIDEO_CB <IC3101-22>
VIDEO_CR <IC3101-23>
AV_HSYNC <IC3101-9> AV_VSYNC <IC3101-4>
AV_R-OUT <TP13R> AV_G-OUT <TP13G>
AV_B-OUT <TP13B>
HD_OUT <TPHD> VD_OUT <TPVD>
GHS_PW <TPGHS>
