MH7-XT1600, MJ7-XT1100
Electrical Parts List
-68-
● OUT OF CIRCUIT BOARD
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Fuse
Thermal Switch
(SW905)
FN905
Cooling Fan
FN903
Cooling Fan
Interlock switch
(SW902)
Audio
Board
RC Board
AV Board
Main Board
Line Filter
Board
Ballast
Board
FN907
Cooling Fan
Sensor
Board
FN902
Cooling Fan
FN904
Cooling Fan
Power DC
Board
FN906
Cooling Fan
COM Board
FN901
Cooling Fan
Power AC
Board
FN900
Lamp Ass’y
Noise Filter
